Module-Steering Column Control C5 (Standard) Connector End View (D3816E)

Harness-Family: Steering_Wheel

Color: BLACK

Gender: FEMALE

Part Number: 33401180

Part Description: Not Available

Connector No: D3816E

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Steering Column Control C5 Connector End View (Standard)
GCWD1000529Courtesy of CHRYSLER
Fig 2: Module-Steering Column Control C5 Component Location (Standard)
GCWD1267763Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 C91 RD 0.50 HEATED STEERING WHEEL FEED HEATED STEERING WHEEL
2 C986 BK 0.50 HEATED STEERING WHEEL RETURN HEATED STEERING WHEEL
(1) Pins not listed are not used for this connector
