Switch-Memory Set (Standard) Connector End View (D2261A)

Harness-Family: Seat_Driver

Color: BLACK

Gender: FEMALE

Part Number: PP10000944

Part Description: Not Available

Connector No: D2261A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Switch-Memory Set Connector End View (Standard)
GCWD1205462Courtesy of CHRYSLER
Fig 2: Switch-Memory Set Component Location (Standard)
GCWD1268186Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 G493 BN/BK 0.5 SEAT SWITCH/SENSOR GROUND N/A
2 G200 GY/DB 0.5 MEMORY SELECT SWITCH MUX N/A
(1) Pins not listed are not used for this connector
