Module-Glow Plug-Eyelet (2.2L) Connector End View (D3913B)

Harness-Family: Engine_22L

Color: BLACK

Gender: FEMALE

Part Number: 1/11242/97

Part Description: Not Available

Connector No: D3913B

Option: 2.2L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Glow Plug-Eyelet Connector End View (2.2L)

Courtesy of CHRYSLER

Fig 2: Module-Glow Plug-Eyelet Component Location (2.2L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A203

2.5

FUSED B(+)

DIESEL

A202

2.5

FUSED B(+)

DIESEL

A204

2.5

FUSED B(+)

DIESEL

A208

2.5

FUSED B(+)

DIESEL

⁽¹⁾	Pins not listed are not used for this connector
