Module-Power Blower Motor-Front C2 (Standard) Connector End View (D6608B)

Harness-Family: HVAC

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-6458-40

Part Description: Not Available

Connector No: D6608B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Power Blower Motor-Front C2 Connector End View (Standard)
GCWD1006456Courtesy of CHRYSLER
Fig 2: Module-Power Blower Motor-Front C2 Component Location (Standard)
GCWD1267749Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 C7 RD 4 BLOWER MOTOR SUPPLY N/A
2 C56 BK 4 BLOWER MOTOR CONTROL N/A
(1) Pins not listed are not used for this connector
