Module-Powertrain Control 2 C1 (2.9L) Connector End View (D3838A)

Harness-Family: Headlamp_Dash

Color: BLACK

Gender: FEMALE

Part Number: 1/11901/07

Part Description: Not Available

Connector No: D3838A

Option: 2.9L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Powertrain Control 2 C1 Connector End View (2.9L)

Courtesy of CHRYSLER

Fig 2: Module-Powertrain Control 2 C1 Component Location (2.9L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K900

2.5

SENSOR GROUND

2.9L

Z108

2.5

GROUND

2.9L

F342

DB/RD

2.5

FUSED ASD RELAY OUTPUT

2.9L

Z108

2.5

GROUND

2.9L

F342

DB/RD

2.5

FUSED ASD RELAY OUTPUT

2.9L

F342

DB/RD

2.5

FUSED ASD RELAY OUTPUT

2.9L

K102

OG/BK

0.5

O2 2/1 PUMP CELL CURRENT TRIM

2.9L

K906

OG/WH

0.5

O2 2/1 RETURN

2.9L

K43

GY/GN

0.5

O2 2/1 SIGNAL

2.9L

C281

OG/WH

0.35

A/C CLUTCH RELAY CONTROL

2.9L

Z107

0.5

GROUND

LHD 2.9L

F145

RD/GN

0.5

BLOW-BY RELAY OUTPUT

2.9L

N46

0.5

LEAK DETECTION PUMP CONTROL

2.9L

K80

1.0

O2 2/1 HEATER CONTROL

2.9L

K71

1.0

EVAP PURGE CONTROL

2.9L

C18

GY/BN

0.35

A/C PRESSURE SIGNAL

2.9L

N47

0.5

LEAK DETECTION PRESSURE SENSOR

2.9L

K619

0.75

ACTUATOR CONTROL

2.9L

N639

YE/BK

0.75

TURBO SURGE VALVE 2 CONTROL

2.9L

K243

DB/GN

0.5

O2 2/2 SIGNAL

2.9L

K908

WH/DB

0.5

O2 2/2 RETURN

2.9L

K900

BK/GN

0.5

SENSOR GROUND

2.9L

K383

DB/OG

0.5

BOOST PRESSURE SIGNAL 2

2.9L

B134

GN/WH

0.5

BRAKE SIGNAL 1

2.9L

F741

OG/DB

0.5

IGNITION RUN/START OUTPUT

2.9L

D468

YE/DB

0.35

PRIVATE CAN (-)

2.9L

D469

YE/GY

0.35

PRIVATE CAN (+)

2.9L

D11

0.35

CAN C (+)

2.9L

D12

0.35

CAN C (-)

2.9L

K855

DB/WH

0.5

5 VOLT SUPPLY

2.9L

N48

DB/RD

0.5

FTIV CONTROL

2.9L

K335

BK/GN

0.75

BLOW-BY RELAY CONTROL

2.9L

K855

WH/RD

0.35

5 VOLT SUPPLY

2.9L

A908

RD/GN

0.5

FUSED B(+)

2.9L

K542

0.5

ASD RELAY CONTROL

2.9L

K399

BN/WH

1.0

O2 2/2 HEATER CONTROL

2.9L

⁽¹⁾	Pins not listed are not used for this connector
