Module-Glow Plug (Standard) Connector End View (D3913A)

Harness-Family: Headlamp_Dash

Color: BLACK

Gender: MALE

Part Number: 1/11239/97

Part Description: Not Available

Connector No: D3913A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Glow Plug Connector End View (Standard)
GCWD1000077Courtesy of CHRYSLER
Fig 2: Module-Glow Plug Component Location (Standard)
GCWD1267657Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 K330 WH/BN 0.35 GLOW PLUG MODULE CTRL EU6
2 K202 WH/DB 0.75 GLOW PLUG RELAY CONTROL DIESEL
3 Z925 VT/BK 0.75 GROUND DIESEL
4 F346 DB/WH 1.0 FUSED ASD RELAY OUTPUT DIESEL
5 A901 RD 6.0 FUSED B(+) DIESEL
(1) Pins not listed are not used for this connector
