Test sequence

Connect VAS 5051 tester. Go to VAS 5051 VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM, CONNECTING AND SELECTING FUNCTIONS . Select vehicle system "01 - Engine electronics". Ignition must be switched on for this.

or, depending on desired operation:

Display on VAS 5051:

Fig 1: Displaying On VAS 5051 - Basic Setting (1 Of 4)

Courtesy of AUDI OF AMERICA, INC.

Display on VAS 5051:

Fig 2: Displaying On VAS 5051 - Basic Setting (2 Of 4)

Courtesy of AUDI OF AMERICA, INC.

1 - Enter display group

Enter desired 3-digit display group number in button field -2- and press -Q- button to confirm input.

Example:

Press buttons -0-, -0- and -1- to select "display group number 001" and press -Q- button to confirm input.

Display on VAS 5051:

Fig 3: Displaying On VAS 5051 - Basic Setting (3 Of 4)

Courtesy of AUDI OF AMERICA, INC.

NOTE: Basic setting is initiated after button -A- is pressed.

Display on VAS 5051:

Fig 4: Displaying On VAS 5051 - Basic Setting (4 Of 4)

Courtesy of AUDI OF AMERICA, INC.
