Cruise control system, activating/deactivating: Procedure: Notes

• Connect VAS 5051 tester. Go to VAS 5051 VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM, CONNECTING AND SELECTING FUNCTIONS . Select vehicle system "01 - Engine electronics". Ignition must be switched on for this.

Display on VAS 5051:

Fig 1: Displaying On VAS 5051 - Cruise Control System (1 Of 2)

Courtesy of AUDI OF AMERICA, INC.

• In selection -1-, select diagnostic function "11 - Coding II".

Display on VAS 5051:

Fig 2: Displaying On VAS 5051 - Cruise Control System (2 Of 2)

Courtesy of AUDI OF AMERICA, INC.

1 - Enter code word
