Diagnostic Trouble Code (DTC) memory, erasing: Preconditions:

• Diagnostic Trouble Code (DTC) memory checked. Go to DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING .
• All malfunctions repaired.

After DTC memory has been successfully checked:

Display on VAS 5051:

Fig 1: Displaying On VAS 5051 - DTC Memory, Erasing (1 Of 2)

Courtesy of AUDI OF AMERICA, INC.

• Under -1- select diagnostic function "05 - Erase Diagnostic Trouble Code (DTC) memory".

Display on VAS 5051:

Fig 2: Displaying On VAS 5051 - DTC Memory, Erasing (2 Of 2)

Courtesy of AUDI OF AMERICA, INC.

1. -
   • No display (before erasing)

   or

   • Diagnostic Trouble Code (DTC) memory erased
   NOTE: The following message appears in display zone -1-: "Diagnostic Trouble Code (DTC) memory not yet checked", if the operational sequence was not exactly performed. The Diagnostic Trouble Code (DTC) memory can only be erased, if the Diagnostic Trouble Code (DTC) memory has been checked beforehand.
2. - Note: Is the function to be carried out?

   Note: Data will be erased!

• Press -OK- button in display -2-.
• Exit function "05 - Erase Diagnostic Trouble Code (DTC) memory" by pressing < button.
• Check Diagnostic Trouble Code (DTC) memory again after performing repairs.
