Coding II table
CODING II
| Empty characters | 00 | |||||
| Country/emissions | 16 | ULEV (emissions regulation) | ||||
| Drive/auxiliary functions | 0 | Front-wheel drive without TCS / ESP | ||||
| 2 | 4WD without traction control system | |||||
| 5 | Front-wheel drive with TCS / ESP | |||||
| 7 | 4WD with traction control system | |||||
| Transmission | 0 | 5-Speed Manual Transmission | ||||
| 5 | Automatic Transmission 01V | |||||
| 8 | Multitronic 01J | |||||
| Model | 1 | Audi A4 |
- Confirm entry with -Q- button.
Display on VAS 5051:
1 - Coding II being carried out
- Wait until next display appears.
Display on VAS 5051:
- - Coding II being carried out in vehicle system
- - Control module identification with new code (previous code in brackets)
- Exit function "07 - Encode Engine Control Module" by pressing the < button.
- Switch ignition off and then switch on again after 15 seconds.
NOTE:
- The next time the ignition is switched on the newly entered code will be activated.
- If the ignition is not switched off and on after the correct code has been entered, it will not be possible to erase DTC "01044 Control module incorrectly coded".
