Test sequence

• Connect vehicle diagnostic, testing and information system VAS 5051 and select vehicle system "01 - Engine electronics" in selection list. Ignition must be switched on.

Display on VAS 5051:

Fig 1: Displaying On VAS 5051 - Output Diagnostic Test Mode

Courtesy of AUDI OF AMERICA, INC.

• Under -1- select diagnostic function "03 - Output Diagnostic Test Mode (DTM)".
