Drain Plug, Inspection Plug And Overflow Tube For Transmission Oil Overview: Notes

NOTE:

Here only pay attention to -19 through 23-.

Fig 1: Identifying Gear Oil Filter Component Overview

Courtesy of AUDI OF AMERICA, LLC

1. 19 - Oil Drain Plug
   • 45 Nm
   • Only early constructions, location DRAIN PLUG, INSPECTION PLUG AND OVERFLOW TUBE FOR TRANSMISSION OIL OVERVIEW
2. 20 - Seal
   • Replace
3. 21 - Inspection Plug
   • 45 Nm
   • Installed location DRAIN PLUG, INSPECTION PLUG AND OVERFLOW TUBE FOR TRANSMISSION OIL OVERVIEW
4. 22 - Seal
   • Replace
5. 23 - Overflow Pipe
   • 3 Nm
   • Installed location DRAIN PLUG, INSPECTION PLUG AND OVERFLOW TUBE FOR TRANSMISSION OIL OVERVIEW
