Lane Change Assistance Control Modules -J769- / -J770-, Removing And Installing: Removing
WARNING: This page is about a different car, the 2021 Audi e-tron Quattro and 2019 Audi e-tron Quattro. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the rear bumper cover. Refer to BUMPER COVER, REMOVING AND INSTALLING .
-- Release the retainers in direction of -arrows-.
-- Release and remove the shield -2- on the Lane Change Assistance Control Module -1-.
-- Release the retainers -4-.
-- Remove the lane change assistance control module -2- from the bracket -3- in direction of -arrow-.
-- Disconnect the connector -1-.
