Front Treble Speaker, Removing And Installing: Removing

WARNING: This page does not describe the selected car, but rather 13 other vehicles, including the 2017 Audi SQ5, 2017 Audi Q5, 2016 Audi SQ5, 2016 Audi Q5, and 2015 Audi SQ5. However, it is still accessible from the selected car via links, so may be relevant.

-- Unclip the speaker trim from the instrument panel.

-- Remove the screws -1- from the Left Front Treble Speaker -R20- -2- and remove the Left Front Treble Speaker -R20- -2- from the instrument panel -3-.

Fig 1: Removing Left Front Mid-Range Speaker -2-

Courtesy of AUDI OF AMERICA, LLC

-- Disconnect the connector from the Left Front Treble Speaker -R20- -2-.

-- Remove the Left Front Treble Speaker -R20- -2- completely from the instrument panel -3-.
