Left/Right Front Bass Speaker -R21- / -R23-, Removing And Installing: Removing

-- Remove the front door trim panel, refer to Front Door Trim .

-- Release and disconnect the connector from the Left Front Bass Speaker -R21- -3-.

Fig 1: Identifying Connector From Left Front Midrange Speaker -R103- -1-

Courtesy of AUDI OF AMERICA, LLC

-- Remove the bolts -4-.

-- Remove the Left Front Bass Speaker -R21- -3-.
