Driver Door Control Module -J386- / Front Passenger Door Control Module -J387-, Removing And Installing

Removing

Fig 1: Driver Door Control Module -J386- And Front Passenger Door Control Module -J387-

Courtesy of AUDI OF AMERICA, LLC

-- Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

-- Open the release and the disconnect the connectors -1- and -2-.

-- Disconnect the connector -3-.

-- Disconnect the connector -4- on the door control module.

-- Press the retaining detent -5- in direction of -arrow- and disengage the door control module -6- on the door shell.

Installing

-- Installation in reverse order of removal making sure the retainer locks into the inner door panel.
