Closing Assist Motor, Removing And Installing

Fig 1: Exploded View Of Door Handle And Door Lock, Closing Assist Motor

GWWA57-10630

Courtesy of AUDI OF AMERICA, LLC

Release Cable
Driver Door Closing Assist Motor -V302-
- Removing
  -- Remove the door trim panel. .

  -- Disconnect the connector from the motor.

  -- Remove the bolts from the motor.

  -- Guide the release cable out of the cable winder.
- Installation
  -- When installing, first insert the cable end into the cable winder.

  -- Place the cable 360° inside the groove in the cable winder.

  -- Install the cable -arrows- into the motor.

  -- Tighten the motor.
Rubber Bushing
- No replacement part
Screw
