Transmission Fluid Temperature Sensor, Transmission Input Speed Sensor, Transmission Output Speed Sensor, Transmission Control Module

G00575739

Courtesy of AUDI OF AMERICA, LLC

G93 Water separator sensor

G182 Transmission input speed sensor

G195 Transmission output speed sensor

J217 Transmission control module

T8m 8-pin connector

T52 52-pin connector
