Vehicle Positioning System Interface Control Module -J843-, Removing And Installing: Removing

Fig 1: Identifying Towing Recognition Control Module, Removal

Courtesy of AUDI OF AMERICA, LLC

-- Open the right luggage compartment side trim panel.

-- Disconnect the connectors -2 and 3-.

NOTE:

Ignore item -1- and -arrow-.

-- Remove the nuts -6 and 7-.

Fig 2: NO CONTENT

Courtesy of AUDI OF AMERICA, LLC

-- Remove mounting bracket.

-- Disconnect the connectors -3 through 5-.

-- Open the clip -arrow- and remove the Vehicle Positioning System Interface Control Module -J843- -item 2- from the mounting bracket -1-.
