Start/Stop System Assembly Overview

Fig 1: Identifying Battery Overview

Courtesy of AUDI OF AMERICA, LLC

Voltage Stabilizer -J532-
- Removing and installing. Refer to VOLTAGE STABILIZER, REMOVING AND INSTALLING .
Nut
- 3 Nm
Nut
- 3 Nm
Cover/Multimedia System Control Head -E380-
Start/Stop Mode Button -E693-
- Various installed locations
- Removing and installing. Refer to Start/Stop Mode Button -E693-, REMOVING AND INSTALLING .
Nut
- 3 Nm
Bracket
- For the Voltage Stabilizer -J532-
Connector
