Effects Speaker -R209- / -R210-, Removing And Installing, Bang & OLUFSEN: Removing

-- Turn off the ignition and all electrical equipment and remove the ignition key.

-- Remove the rear shelf. Refer to appropriate service information. .

-- Remove the bolts -arrows- from the Right Effects Speaker -R209- -1-.

Courtesy of AUDI OF AMERICA, LLC

-- Release and disconnect the connector -2- from the Left Effects Speaker -R209- -1-.

-- Remove the Left Effects Speaker -R209- -1- upward from the rear shelf -3-.
