Abs Control Module, Data Bus On Board Diagnostic Interface, Engine/Motor Control Module

Courtesy of AUDI OF AMERICA, LLC

J104

ABS Control Module

J533

Data Bus on Board Diagnostic Interface

J623

Engine/Motor Control Module

T46a

46-Pin Connector, Black

T54a

54-Pin Connector, Black

T56f

56-Pin Connector, Black

T91a

91-Pin Connector, Black

*

Refer to Applicable Engine Wiring Diagram

*2

For Vehicles Without Adaptive Cruise Control (ACC)

*3

For Vehicles with 2.0L Gasoline Engine

*4

For Vehicles with Gasoline Engine

*5

For Vehicles with Diesel Engine

*6

For Vehicles with Adaptive Cruise Control (ACC)
