Hydramatic Pressure Regulator

The valve body shown at the right is from the A5S360/390R. Note the location of the main pressure regulator. Depending upon the reference text, the pressure regulator is also known as the Force Motor Solenoid, Variable Bleed Solenoid or PC Solenoid.

Fig 1: Identifying Hydramatic Pressure Regulator
G03403800Courtesy of BMW OF NORTH AMERICA, INC.
