61 35 177 Removing and installing (replacing) rain/light sensor

IMPORTANT: Read and comply with notes on protection against electrostatic damage (ESD PROTECTION) .

Necessary preliminary tasks:

Version with Autobeam:

Detach two-part mirror base cover (1) by pressing from below.

Feed out two-part mirror base cover (1) and remove.

NOTE: Catches of two-part mirror base cover (1) must not be damaged or missing.

Fig 1: Removing Mirror Base Cover

Courtesy of BMW OF NORTH AMERICA, INC.

Disconnect plug connection (3).

Release locks (1) in direction of arrow and remove rain/light sensor (2) from optical element.

Installation:

Do not damage optical element covered by rain/light sensor (2).

Fig 2: Removing Rain/Light Sensor From Optical Element

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:
