Bus System Overview for Vertical Dynamics Systems

Fig 1: Bus System Overview For Vertical Dynamics Systems

Courtesy of BMW OF NORTH AMERICA, INC.

INDEX REFERENCE CHART

Index	Explanation
EHC	Electronic ride-height control
ZGM	Central Gateway Module
DME	Digital Motor Electronics
DSC	Dynamic stability control
SZL	Steering column switch cluster
ICM	Integrated Chassis Management
VDM	Vertical Dynamics Management
EDC SVL	Electronic Damper Control satellite, front left
EDC SHL	Electronic Damper Control satellite, rear left
EDC SVR	Electronic Damper Control satellite, front right
EDC SHR	Electronic Damper Control satellite, rear right
