61 13... Round connector, 20-pin, system D2.5

Carefully press back retaining lugs (1) of internal connector (2).

Fig 1: Moving Lower Section Of Connector In Specified Direction

Courtesy of BMW OF NORTH AMERICA, INC.

Turn internal connector (2) until retaining lugs (1) snap into release groove (3).

Fig 2: Turning Internal Connector

Courtesy of BMW OF NORTH AMERICA, INC.

With special tool 61 1 132 (pressing-off tool), press back retaining hooks (4) of appropriate contact and pull out cable.

Fig 3: Pressing Back Retaining Tabs Of Internal Connector

Courtesy of BMW OF NORTH AMERICA, INC.
