Fuel Injector
- With fuel meter cover gasket in place, use a screwdriver to carefully pry the injector from the fuel metering body. Carefully lift injector out with a twisting motion. See Figure
.
NOTE:
Use care in removing injector to prevent damage to electrical connectors, fuel filter and nozzle. Injector is serviced as complete assembly only.
- Remove small "O" ring from the nozzle end of injector. Carefully rotate injector filter back and forth to remove from base of injector. Remove large "O" ring and steel back-up washer at top of injector cavity in fuel meter body.
