Control Units

CONTROL UNITS LOCATION

Component Location
ABS Control Module Under left corner of rear floor, in storage compartment.
A/C-Heater Programmer Behind left side of dash, right of steering column.
Blower Control Module (Auto. A/C) In left side of engine compartment, on firewall.
Central Control Module (CCM) Behind center of dash. See Figure .
Cruise Control Module Behind right side of dash, near radio receiver box.
Daytime Running Light Module Behind center of dash. See Figure .
Diode Module Behind right side of dash.
Electronic Control Module (ECM) On left side of engine compartment, near battery. See Figure .
Headlight Door Control Unit In lower left front of engine compartment.
Inflator Module Middle of steering wheel.
Low Tire Pressure Warning System Module Behind left side of dash. See Figure .
Select Ride Control Module (Opt.) Under left corner of rear floor, in storage compartment.
Wiper/Washer Motor Module On left side of firewall.
