Cruise Control Switch: Service and Repair

1. Remove steering wheel, lower steering column covers and steering lock plate cover, if equipped.
2. Disconnect cruise control connector from main harness connector and attach a suitable length of flexible wire to cruise control harness.

Fig. 10 Cruise Control Switch replacement:

3. Tape joint between main and control harness to aid removal, then remove control assembly, Fig. 10.
4. Reverse procedure to install.
