PCM Connector C2
NOTE:
For terminal identification, see
Figure
.
Fig 1: PCM C2 80-Pin Connector (Clear) - Legend (1 Of 2)
Courtesy of GENERAL MOTORS CORP.
Fig 2: PCM C2 80-Pin Connector (Clear) - Legend (2 Of 2)
Courtesy of GENERAL MOTORS CORP.
