Electronic Brake Control Module (EBCM)

Removal Procedure





1. Remove the IP sound insulator panel. Refer to Trim Pad Replacement - IP in Instrument Panel, Gauges and Warning Indicators.
2. Use pressure tabs in order to release the EBCM (1) from the EBCM bracket (2).
3. Remove the EBCM electrical connectors.

Installation Procedure





1. Install the EBCM electrical connectors.
2. Slide the EBCM (1) into the EBCM bracket (2) until pressure tabs secure the EBCM.
3. Install the IP sound insulator panel. Refer to Trim Pad Replacement - IP in Instrument Panel, Gauges and Warning Indicators.
