Removal Procedure

  1. Close the sunroof.
  2. Lower the headliner as necessary. Refer to HEADLINER REPLACEMENT in Interior Trim.
  3. Disconnect the wire harness connectors from both ends of the sunroof control module (8).
  4. Remove the nylon tie straps from the control module (8).
  5. Remove the control module (8) from the sunroof assembly by sliding the control module towards the right of the vehicle.
    Fig 1: Removing Control Module From Sunroof Assembly
    G01590626Courtesy of GENERAL MOTORS CORP.
