Engine Control Module: Locations



POWERTRAIN CONTROL MODULE

Below The Left Side Of The IP, Near The Steering Column:






The Powertrain Control Module is located below the left side of the instrument panel, near the steering column.

1. IP Harness
2. Engine Harness
3. Powertrain Control Module Connectors
4. Body Harness
5. Rear Compartment Lid Release Switch
