Coolant Temperature Sensor/Switch (For Computer): Locations

Powertrain Component Views

Front and Rear of Engine (LAT or LE5)




1 - Knock Sensor (KS)
2 - Heated Oxygen Sensor (HO2S) 1
3 - Heated Oxygen Sensor (HO2S) 2
4 - Engine Coolant Temperature (ECT) Sensor
