Electronic Traction Control Switch Replacement

Fig 1: View Of Traction Control Switch
GM1616865Courtesy of GENERAL MOTORS COMPANY
Electronic Traction Control Switch Replacement

Callout Component Name
Fastener Tightening Specifications:  Refer to Fastener Tightening Specifications .
1 Switch Assembly, Headlamp Instrument Panel Dimmer
  • The traction control switch is part of the headlamp switch and must be serviced as an assembly.
  • Disconnect the electrical connector.
