Rear of Engine Components
Rear of Engine Components
| Items |
|---|
| 1: B23E Camshaft Position Sensor - Exhaust B23E Camshaft Position Sensor - Exhaust |
| 2: B19C Brake Booster Vacuum Switch B19C Brake Booster Vacuum Switch |
| 3: B68 Knock Sensor B68 Knock Sensor |
| 4: G13 Generator G13 Generator |
| 5: M64 Starter Motor M64 Starter Motor |
| 6: E41 Engine Coolant Thermostat Heater E41 Engine Coolant Thermostat Heater |
| 7: B34A Engine Coolant Temperature Sensor 1 B34A Engine Coolant Temperature Sensor 1 |
| 8: B23F Camshaft Position Sensor - Intake B23F Camshaft Position Sensor - Intake |
