Rear of Engine Components - 1.4L
Rear of Engine Components - 1.4L
| Component Name | Callout |
|---|---|
| B23F Camshaft Position Sensor - Intake B23F Camshaft Position Sensor - Intake | 1 |
| Q6F Camshaft Position Actuator Solenoid Valve - Intake Q6F Camshaft Position Actuator Solenoid Valve - Intake | 2 |
| Q6E Camshaft Position Actuator Solenoid Valve - Exhaust Q6E Camshaft Position Actuator Solenoid Valve - Exhaust | 3 |
| Q40 Turbocharger Bypass Solenoid Valve Q40 Turbocharger Bypass Solenoid Valve | 4 |
| G13 Generator G13 Generator X1 , and G13 Generator X2 | 5 |
| B52B Heated Oxygen Sensor 2 B52B Heated Oxygen Sensor 2 | 6 |
| B26 Crankshaft Position Sensor B26 Crankshaft Position Sensor | 7 |
| M64 Starter Motor M64 Starter Motor X1 , and M64 Starter Motor X2 | 8 |
| B68 Knock Sensor B68 Knock Sensor | 9 |
