Passenger Switch Replacement

REMOVAL

Negative Battery Cable Remote Terminal:

1. Open hood and disconnect the negative battery cable remote terminal from the remote battery post.
2. Remove passenger door trim panel.
3. Disconnect switch wire connector.
4. Remove switch from bezel and vehicle.

INSTALLATION
For installation, reverse the above procedures.
