Torque Specifications

TORQUE SPECIFICATIONS

Component Ft. Lbs. (N.m)
Wheel Nut 81 (110)
INCH Lbs. (N.m)
Tire Pressure Sensor Nut (1) 35 (4)
(1) Once tightened, the gap between the sensor and the wheel must be even on both sides as shown. See Figure. If the sensor/transmitter rotates (clocks), damage to the sensor/transmitter can occur when mounting the tire.
