Traction Control Switch: Removal

NOTE: Before proceeding, review all WARNINGS and CAUTIONS. (Refer to STEERING/COLUMN - WARNING) and (Refer to STEERING/COLUMN - CAUTION) .

Open hood and remove remote ground cable from ground stud on left front shock tower. Isolate ground cable from vehicle by installing cable isolator on ground stud. See Fig 1.

Fig 1: Correctly Isolated Remote Ground Cable
Courtesy of DAIMLERCHRYSLER CORP.

1 - LEFT STRUT TOWER

2 - GROUND STUD
Remove instrument panel trim bolster below steering column. (Refer to BODY/INSTRUMENT PANEL/INSTRUMENT PANEL TRIM - REMOVAL) .
Disconnect traction control "OFF" switch wiring connector at column harness.

Remove 2 screws attaching upper and lower shrouds to steering column. See Fig 2.

Fig 2: Steering Wheel And Shroud Mounting

Courtesy of DAIMLERCHRYSLER CORP.

1 - UPPER SHROUD

2 - BOLT

3 - STEERING WHEEL

4 - LOWER SHROUD

Remove upper shroud (with switch) from steering column by pressing inward on upper shroud just above the parting line while pulling upper and lower shrouds apart.
Release tilt lever and tilt steering column to its highest point, then remove lower shroud from steering column.
Disengage retaining tab and remove traction control "OFF" switch from upper shroud. See Fig 3.

Fig 3: Traction Control Switch

Courtesy of DAIMLERCHRYSLER CORP.

1 - UPPER SHROUD

2 - TRACTION CONTROL "OFF" SWITCH
