Steering Column Lock Module (Export) Connector End View
MODULE-STEERING COLUMN-LOCK - 4 WAY (EXPORT)
 Courtesy of CHRYSLER CORP.
|
| CAV |
CIRCUIT |
FUNCTION |
| 1 |
A952 20RD/TN |
FUSED B(+) |
| 2 |
Z910 20BK/TN |
GROUND |
| 3 |
F892 20PK/LB |
IGNITION SWITCH OUTPUT (KEY-IN) |
| 4 |
D508 20WT/GY |
COM-LIN TIRE PRESSURE MONITOR LAN |
