Relay Test

Remove the starter relay as described in this group to perform the following tests:

1. A relay in the de-energized position should have continuity between terminals 87A and 30, and no continuity between terminals 87 and 30. If OK, go to  2. If not OK, replace the faulty relay.
2. Resistance between terminals 85 and 86 (electromagnet) should be 75 ±5 ohms. If OK, go to  3. If not OK, replace the faulty relay.
3. Connect a battery B+ lead to terminals 85 and a ground lead to terminal 86 to energize the relay. The relay should click. Also test for continuity between terminals 30 and 87, and no continuity between terminals 87A and 30. If OK, refer to RELAY CIRCUIT TEST . If not OK, replace the faulty relay.
   Fig 1: Starter Relay Pinout

   Courtesy of CHRYSLER LLC
   Fig 2: Starter Relay Pinout

   Courtesy of CHRYSLER LLC

   30	COMMON FEED
   85	COIL GROUND
   86	COIL BATTERY
   87	NORMALLY OPEN
   87A	NORMALLY CLOSED

   Fig 3: Starter Relay Pinout

   Courtesy of CHRYSLER LLC
