Engine Coolant Temperature Sensor - Removal

2.7L










1. Disconnect negative battery cable.
2. Partially drain cooling system Service and Repair.
3. Disconnect the electrical connector (2).
4. Remove engine coolant sensor (1) from coolant outlet tube (3).
