P1E1D-00-Control Module Improper Wake-Up Performance: Notes

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article  .

Fig 1: Battery Charging Circuit Diagram
GC0157956Courtesy of CHRYSLER GROUP, LLC
