Module-Steering Control C3

Harness-Family: Steering_Wheel

Color: WHITE

Gender: FEMALE

Part Number: 174463-1

Part Description:070 SRS MLC 2POS PLUG HOUSING

Connector No: D3816C

Option: Standard

Repair Kit Part Number: 68068651AA

Cavity Count: 2

Fig 1: Module-Steering Control C3 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Steering Control C3 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R63

DRIVER SQUIB 2 LINE 1

N/A

R61

DRIVER SQUIB 2 LINE 2

N/A

⁽¹⁾	Pins not listed are not used for this connector
