Liftgate Release Switch - Power: Notes

Fig 1: Liftgate Release Switch - Power With Torque Specifications
GF0043816Courtesy of FORD MOTOR CO.
Item Part Number Description
1 W505423 Liftgate release switch molding bolts (2 required)
2 13508 Liftgate release switch molding
3 - Liftgate release switch electrical connector (part of 14A583)
4 14018 Liftgate release switch
