Intake Manifold
Intake ManifoldPosition the intake manifold and install the 5 bolts.
Tighten to 18 Nm (159 lb-in).
Throttle Body
Position the TB shield and install the 2 bolts.
Tighten to 8 Nm (71 lb-in).
Position the intake manifold and install the 5 bolts.
Tighten to 18 Nm (159 lb-in).
Throttle Body
Position the TB shield and install the 2 bolts.
Tighten to 8 Nm (71 lb-in).
