Sensor-Headlamp Level-Rear

Component ID: 512
Component : SENSOR-HEADLAMP LEVEL-REAR

Connector:
Name : SENSOR-HEADLAMP LEVEL-REAR
Color :
# of pins : 4
Gender : FEMALE




Pin Circuit Description
1 2474 20WT/BR SENSOR GROUND
2 2476 20WT/RD SENSOR SUPPLY
3 - -
4 2475 20WT/DG REAR HEADLAMP LEVEL SIGNAL
