Sensor-Swirl-Left

Component ID: 549
Component : SENSOR-SWIRL-LEFT

Connector:
Name : SENSOR-SWIRL-LEFT
Color : BLACK
# of pins : 3
Qualifier : (DIESEL)




Pin Circuit Description
1 4253 20RD/YL SENSOR SUPPLY
2 4252 20PK/BK LEFT SWIRL SIGNAL
3 4251 20BK/PK SENSOR GROUND
