Vehicle Speed Sensor: Diagrams

Component ID: 551
Component : SENSOR-VEHICLE SPEED

Connector:
Name : SENSOR-VEHICLE SPEED C1
Color :
# of pins : 1
Gender : FEMALE




Pin Circuit Description
1 3104 18BR -



Connector:
Name : SENSOR-VEHICLE SPEED C2
Color :
# of pins : 1
Gender : FEMALE




Pin Circuit Description
1 3105 18WT -
